Furniture Quality Woodwork
Beautifully presented with rounded top edges at the front and rear, each speaker cabinet uses a sandwich construction of alternate layers of MDF and high-density particleboard to reduce panel resonance to below the level of audibility.
Aesthetically, the look is classically Quad, yet subtly updated, available initially in black or sapele mahogany wood veneers. These will be joined in the autumn by premium, hand-laquered piano white and piano black finish options.
Delicate Sound, Powerful Delivery
All S Series models sport a bespoke ribbon treble unit, delivering effortlessly extended high frequencies that are audibly superior to those supplied by typical dome tweeters.
While many ribbon drivers are delicate, easily prone to burning out if overpowered, the new ribbon unit developed for the S Series is a thoroughly modern affair, utilising the latest techniques and materials. The ribbon itself is a sandwich construction, making it robust enough to handle high-powered amplifiers, and is fully immersed in a powerful magnetic field so that it accomplishes its dual role of being both the voice coil and sound radiator.
As well as delivering excellent transient response and superb musical detail, the sound from this ribbon unit is smooth right up to the highest musical overtones beyond the limits of human hearing. Controlled directivity maintains this sound quality over a wide horizontal arc to cover all listeners whilst vertical dispersion is tailored to avoid floor and ceiling reflections, resulting in the purest high frequency performance at the listening seat.
General description 2-way centre speaker Enclosure type vented box loudspeaker Transducer complement 2-way Bass / Midrange driver 100mm Woven Carbon fibre Cone x2 Treble driver 12 x 45 mm True Ribbon AV shield No Sensitivity (2.83V @ 1m) 86dB Recommended amplifier power 25-150W Peak SPL 97dB Nominal impedance 8Ω Compatible Minimum impedance 4.4Ω Frequency response (+/-3dB) 65Hz ~ 20kHz Bass extension (-6dB) 60Hz Crossover frequency 2.8kHz Cabinet Volume (in litres) 12.8L Dimensions (H x W x D) (160+5) x 400 x (200+30)mm Weight 6.3kg
